Astralpool APS700B Side Mount FG Sand Filter 28" with Multiport Valve - 60028

Astralpool APS700B Side Mount FG Sand Filter 28" with Multiport Valve - 60028

• We keep these physically in stock for fast shipping or local pick-up, unlike most drop-shipping websites.
• Shipped from VIC, NSW, WA, QLD

Complete Astralpool APS700B fibreglass media filter, 28" tank, supplied with its side-mount multiport valve. Bobbin-wound fibreglass construction with UV-stabilised resin - non-corrosive and built for Australian outdoor conditions.

Top Mount or Side Mount? Height Is the Deciding Factor

The two FG ranges filter identically at the same tank size. The difference is where the multiport valve sits, and therefore how tall the installed filter is:

• APV (top mount) - valve on top of the tank. Simpler plumbing, smaller footprint, but taller overall and you need clearance above the tank to service the valve.
• APS (side mount) - valve on the side. Built for height-restricted installs.

At 25" the side mount saves 100mm (850mm vs 950mm). At 28" it saves 202mm (890mm vs 1092mm). If the filter goes under a deck, in a pump enclosure or beneath a bench, measure your headroom first - that measurement usually decides the range for you.

FG Range at a Glance

Model	Mount	Tank	Filter area	Height	Max flow rate
APV650	Top mount	25" / 635mm	0.32 m²	950mm	260 LPM
APV700B	Top mount	28" / 723mm	0.41 m²	1092mm	336 LPM
APV800	Top mount	32" / 800mm	0.50 m²	1200mm	415 LPM
APV900	Top mount	36" / 900mm	0.64 m²	1300mm	520 LPM
APS650	Side mount	25" / 635mm	0.32 m²	850mm	260 LPM
APS700B	Side mount	28" / 723mm	0.41 m²	890mm	336 LPM

Match the Filter to Your Pump - Not the Other Way Around

Astralpool is explicit about this: the pump's flow rate must not exceed the filter's maximum flow rate. An oversized pump on an undersized filter pushes water through the media too fast to filter properly, channels the bed, and shortens the life of the internals.

Check your pump's rated flow against the figures in the table above before ordering. If you are not sure what your pump delivers, send us the pump model and we will work it out with you.

Specifications

• Part number: 60028
• Model: Astralpool APS700B
• Mount: side mount
• Tank diameter: 28" (723mm)
• Filter area: 0.41 m²
• Height: 890mm
• Maximum flow rate: 336 LPM
• Tank: bobbin-wound fibreglass, UV-stabilised
• Internals: 1" diameter collector arms, PVC diffuser
• Multiport valve: 6 + 1 position (filter, backwash, rinse, recirculate, waste, closed)
• Fitted with pressure gauge and manual air and water purge valves
• Barcode: 9317545284934

What Else You Will Need

Filter media is supplied separately. Quantity depends on tank size - contact us with your model and we will confirm how much sand or glass media to order. You may also need barrel unions to suit your existing plumbing.

Related FG Filter Parts

• APS650 FG Filter Tank Only, 25" - 60025T
• APS700B FG Filter Tank Only, 28" - 60028T
• Drain Screw 3/8, FG Filter - 75950
• Drain Nut, Plastic, FG Filter - 75952
• Drain Gasket, FG Filter - 75955
• Collector Arm 310mm, FG905 - 03010104-0003
• Hub Breath Pipe, FG805 / FG905 - 03010103-0011

Frequently Asked Questions

What is the difference between the APS and APV filters?
APS is side mount and APV is top mount. At the same tank size they filter identically - the side mount is 100mm to 200mm shorter installed, so it suits height-restricted spots like under a deck or inside a pump enclosure.

Is filter media included?
No. Sand or glass media is supplied separately. Contact us with your model and we will confirm the quantity required.

How do I know this filter suits my pump?
Compare your pump's rated flow rate against the filter's maximum flow rate of 336 litres per minute. The pump must not exceed it. Send us your pump model if you are unsure.

Can I buy just the tank?
Yes. Tank-only versions are listed separately for both the side mount and top mount ranges.

---

Manufacturer Catalogues, Diagrams & Part Numbers: Need exploded views, spare part numbers, product numbers, diagrams, or more product information? See the manufacturer catalogues below.

• Astralpool Catalogue 2026 | Zodiac Catalogue 2026

Important Before Ordering: Please ensure you order correctly. Confirm this product is suitable before ordering. Use the catalogues above, seek professional assistance, or contact us with photos of your existing part, model details, serial numbers, and any labels.

As with all products, these must be diagnosed and fitted by a qualified and experienced person.

---
