Astralpool Viron iHPt Heat Pumps for Pool & Spas - Top Discharge

Astral Pool & Spa Heat Pumps. Astralpool's range of heat pumps have been available for several years, and have only improved over that time. Astral has one of the largest support networks available. The iHPt series is their top-discharge premium Viron series heat pump.

• Sold within Victoria only & prices cannot be shown due to the Fluidra dealer agreement. All authorised Fluidra (Astralpool/Zodiac) dealers can only sell within their home state.
• Click here to fill out our detailed Heater Evaluation form. Filling out this form will give you the most accurate recommendations for sizing of a heat pump for a pool or spa.

Brochure | Manual


Information:

• Environmentally Friendly pool heating extend your swimming season or swim all year round
• Whisper quiet
• Super Efficient
• Maintains the pool temperature 24 hours a day
• Fast heat-up times
• Reduced temperature when the pool is not in use
• Low operating Costs
• Inverter models are able to be controlled remotely though the HeatPumpGo App (available on Android and iOS)

Viron Top-Discharge Series:

• Viron iHPt127 - 12.7kW -  10A Single-phase
• Viron iHP168 - 16.8kW - 13.5A Single-phase
• Viron iHP246 - 24.6kW - 22.5A Single-phase

Model No.	iHPt127	iHPt168	iHPt246
Technology
AquaTemp app	Yes	Yes	Yes
Viron connect compatible	Yes	Yes	Yes
Wifi module included	Yes	Yes	Yes
Pool Coverage
Heating capacity	5.66-12.17 kW	5.61-12.58 kW	4.98-12.55 kW
Water flow volume	70.00 L/m	91.67 L/m	138.33 L/m
Equipment
Input power	0.23-2.12	0.31-3.05	0.47-4.94
Water pressure drop (max)	4.5 Kpa	4.5 Kpa	6 Kpa
Water connection	40mm	40mm	40mm
Sound pressure 1M Db(A)	44-54	46-56	50-60
Power	15A Plug	Single	Single
Voltage/Phases/Frequency	230V/1P/50Hz	230V/1P/50Hz	230V/1P/50Hz
Average running current	30	50	50
Refridgerant type	R410A	R410A	R410A
Efficiency	2.8-12 COP	3.9-17.1 COP	5.9-24.6 COP
Dimensions (L x W x H)	723x835x865 mm	723x835x865 mm	770x990x970 mm
