The Rheem RPH013-1A 13kW is one of the most popular sizes in Rheem's Compact Residential Inverter range — a strong match for small-to-medium pools and large spas. It combines Rheem's national service backing with full inverter efficiency, built-in WiFi, and one of the strongest warranties on the Australian market.
Rheem is one of Australia's most recognised names in water heating, and Rheem Thermal is a long-established specialist in pool and spa heating for residential and commercial applications. The Compact Residential Inverter Series combines modern inverter efficiency, quiet operation, WiFi control, strong build quality, and one of the best warranty structures in the market.
At a Glance — 13kW (RPH013-1A)
- Heating capacity: 13.0 kW (at 27°C air / 27°C water)
- Average COP at 50% speed: 9.5
- Power supply: 240V single phase
- Recommended circuit breaker: 16A
- Sound level at 10m: 22.2-30.8 dB(A)
- Operating air range: -5°C to +43°C
- Refrigerant: R32 (0.75 kg)
- Advised water flow: 1.2-1.7 L/sec
- Dimensions (L × W × H): 890 × 430 × 657 mm
- Net weight: 61 kg
- Water connections: 50mm
Best suited to small-to-medium in-ground pools and large spas. For smaller spa-only needs, see the 9kW. For larger pools, see the 16kW, 21kW or 28kW models in the same series.
Why We Like Rheem Heat Pumps
- Excellent national backup support from a brand Australians already know and trust
- Heating and cooling capability for better year-round pool and spa comfort
- Built-in WiFi control via app connectivity
- Compact footprint for installations where space matters
- Quiet inverter operation with advanced EC fan motor technology
- High temperature settings for spa applications
- Ready integration with pool automation systems
Warranty Support That Actually Means Something
Not all warranties are equal. Rheem backs the Compact Series with its National Service Network, which is a major advantage over many lesser-known import brands.
- 3 year parts and labour warranty
- 5 years on general parts
- 10 years on the compressor
- 25 years on the heat exchanger
One standout warranty feature: if the heat exchanger fails within the 3 year comprehensive warranty period, Rheem states they will replace the heater at no cost. That is a serious level of support and one of the strongest warranty offers available in this category.
Key Features (All Models)
- Twin rotary stepless DC inverter compressor for efficient, precise output control
- EC fan motor for quiet operation and improved efficiency
- Electronic Expansion Valve (EEV) for increased temperature stability
- Twisted titanium heat exchanger for effective heat transfer and corrosion resistance
- Advanced reverse cycle defrosting for improved cold-weather operation
- R32 refrigerant with lower global warming impact than older refrigerants
- Durable ABS and aluminium alloy casing for outdoor durability
- Single point condensate drain with factory supplied drain kit
- Heavy duty weather cover to help keep the unit clean when not in use
- 50mm water connections
Control and Automation
- Easy-use LCD touchscreen with lock function
- WiFi enabled for remote control through a compatible app
- Suitable for spa temperature settings
- Can integrate with automation systems
- Easy connection to the Rheem DPi Link for automated pump control
Australian Compliance and Peace of Mind
These units are independently certified in Australia to comply with Australian Electrical Safety Standards.
- Certified to AS/NZS 60335-1
- Certified to AS/NZS 60335-2-40
Why Buy From Us
- Authorised Australian supplier
- Physical stock for fastest dispatch or local collection
- Real-world product knowledge in pool and spa heating
Full Range Comparison — Rheem Compact Residential Inverter Series
| Model | RPH009-1A | RPH013-1A | RPH016-1A | RPH021-1A | RPH028-1A | RPH028-3A | RPH035-3A |
|---|---|---|---|---|---|---|---|
| Heating Performance Condition: Air 27°C / Water 27°C / Humidity 80% | |||||||
| Heating Capacity (kW) | 8.6 | 13 | 15.5 | 21 | 27.8 | 27.8 | 35.0 |
| COP Range | 14-6.5 | 14-6.4 | 15-6.5 | 15-6.5 | 15.8-7.2 | 15.6-7.1 | 15.3-7.0 |
| Average COP at 50% Speed | 9.0 | 9.5 | 9.6 | 9.3 | 11.0 | 10.7 | 10.6 |
| Heating Performance Condition: Air 15°C / Water 26°C / Humidity 70% | |||||||
| Heating Capacity (kW) | 6.4 | 9.0 | 10.9 | 14.5 | 18.8 | 18.8 | 24 |
| Cooling Performance Condition: Air 35°C / Water 28°C / Humidity 80% | |||||||
| Cooling Capacity (kW) | 4.4 | 5.9 | 7.8 | 9.9 | 11.7 | 11.7 | 16.0 |
| Technical Specifications | |||||||
| Operating air temperature (°C) | -5 to 43 | -10 to 43 | |||||
| Power supply | 240V 1Ph | 415V 3Ph | |||||
| Rated input power (kW) | 0.21-1.42 | 0.31-2.10 | 0.37-2.42 | 0.47-3.20 | 0.50-3.84 | 0.50-3.84 | 0.65-4.80 |
| Recommended circuit breaker (A) | 10 | 16 | 20 | 25 | 25 | 10 | 20 |
| Sound level at 10m dB(A) | 19.0-28.4 | 22.2-30.8 | 21.2-34.4 | 23.4-34.1 | 21.5-32.9 | 21.5-32.9 | 21.5-32.9 |
| Refrigerant R32 (kg) | 0.5 | 0.75 | 0.8 | 1.0 | 2.0 | 2.0 | 2.0 |
| Advised water flow (L/sec) | 0.5-1.2 | 1.2-1.7 | 1.7-2.3 | 2.0-2.8 | 2.8-3.4 | 2.8-3.4 | 3.3-5.0 |
| Dimensions L / W / H (mm) | 890/430/657 | 890/430/657 | 890/430/657 | 1060/430/657 | 1060/430/957 | 1060/430/957 | 1314/512/957 |
| Net weight (kg) | 58 | 61 | 64 | 70 | 94 | 99 | 132 |
| Water connections (mm) | 50 | ||||||
| Protection level | IPX4 | ||||||
RPH009-1A, RPH013-1A, RPH016-1A and RPH021-1A operate normally in air temperatures from -5°C to +43°C; RPH028-1A, RPH028-3A and RPH035-3A operate normally from -10°C to +43°C. Performance varies with installation, flow rate, ambient temperature and humidity. Specifications may change without notice.
For a side-by-side overview of every size in this range (9kW through 35kW), see the Rheem Compact Inverter Series — Range Overview.
