Astralpool Halo Pro 45 Salt Chlorinator & Pool Automation Controller 20378
Part Number: 20378
- Genuine Authorised Fluidra Dealer & Warranty Agent
- Coming Soon
Expected release: 2027. Halo Pro is a forthcoming new-generation platform and is not the same product as the current Astralpool Halo Chlor system. The information below is based on Fluidra's pre-launch material and will be updated when final documentation is released.
Astralpool Halo Pro sits at the top of Fluidra's new chlorination and automation range, above the Solo and Echo controllers. At 45 grams per hour this is the largest model in the standard Halo Pro range. It combines salt chlorination with full pool automation, and is intended for installations where Echo's single-pool equipment control is not enough - combined pool and spa systems, additional pumps, water features and automated valves.
Automation and Equipment Control
- Built for combined pool and spa installations, coordinating equipment across multiple operating modes
- Valve actuator control for automated changeover between configurations such as pool and spa
- Additional pumps and pool features
- Bluetooth-connected peripheral modules that link back to the controller, so automation is not limited to equipment wired directly into the chlorinator
- Compatible with Fluidra's Bluetooth filter-pressure sensor, which sets a clean-filter baseline and flags when pressure has risen enough to warrant a clean or backwash
Water Chemistry Control
Halo Pro is built for closed-loop chemical control using pH and ORP (redox) sensing, so dosing responds to measured water chemistry. This is the main chemical difference from the Astralpool Echo, which doses acid to a programmed schedule without measuring actual pH. Where the controller needs to react to real readings rather than dose a set amount, Halo Pro is the correct system.
Specifications
- Chlorine output: 45 grams per hour
- Designed around a recommended salinity of approximately 4,000 ppm
- Self-cleaning cell with WWDG technology
- Connected-device security support: to 31 December 2030
Pool volume ratings, dimensions, electrical ratings, pump and lighting compatibility, cell specifications, warranty terms and pricing have not yet been published by Fluidra.
Halo Pro or Halo Chlor?
Halo Pro (20375, 20376, 20377, 20378) is a new platform with its own product numbers, controller architecture and Bluetooth peripherals. It is separate from the current Halo Chlor range (20385, 20386, 20387, 20388), which remains available now. Parts, compatibility and installation requirements are not interchangeable between the two.
Manufacturer Catalogues, Diagrams & Part Numbers
Need exploded views, spare part numbers, product numbers, diagrams, or more product information? See the manufacturer catalogues: Astralpool Catalogue 2026 | Zodiac Catalogue 2026
Important Before Ordering: Please ensure you order correctly. Confirm this product is suitable before ordering. Use the catalogues above, seek professional assistance, or contact us with photos of your existing equipment, model details, serial numbers, and any labels.
As with all products, these must be installed and commissioned by a qualified and experienced person.
Common search terms
Astralpool Halo Pro, Halo Pro 45, 20378, Fluidra Halo Pro, pool and spa automation controller, ORP chlorinator, pH control chlorinator, valve actuator pool controller, WWDG technology chlorinator, SpaPro chlorinator, WWDG pool automation.
To the layperson, plumbing sizes and their names can be confusing due to the nominal sizes and naming conventions used.
This is not something we made up. Plumbers and manufacturers have used nominal (meaning ‘by name only’) sizing for decades.
Simply put, in plumbing, named sizes are often not the actual measurements of the pipe, fitting, or part. A PVC pipe called “50mm” or “2"” does not measure 50 mm anywhere. Instead, it follows nominal sizing, an internationally-standardised naming system.
Almost all fittings we use in the pool & spa industry use “pressure PVC” pipe & fittings. Do not confuse with “DWV” or other pipe & fittings and their names and sizes.
Use the Outside Diameter (OD) to check your pipe against fittings. Below is a quick reference for common spa & pool pipe sizes:
| Imperial Name | Metric Name | Pipe Diameter (OD) |
|---|---|---|
| 1/2" | 15mm | ~21.2–21.5 mm |
| 3/4" | 20mm | ~26.6–26.9 mm |
| 1" | 25 mm | ~33.4–33.7 mm |
| 1.5" | 40 mm | ~48.1–48.4 mm |
| 2" | 50 mm | ~60.2–60.8 mm |
| 2.5" | 65 mm | ~75.2–75.5 mm |
To reiterate, these are nominal sizes and are designed to fit matching fittings — not to measure what their name suggests. These are based on PVC Pressure Pipe AS/NZ 1477 Dimensions1.
- º Internal diameters vary slightly by manufacturer and class.
- 1 Not all pool/spa fittings match these dimensions exactly. Some do not follow Australian or international standards. Chinese spas may use proprietary fittings.
Understanding Plumbing Sizes & Nominal Measurements
Plumbing sizes can be confusing. PVC and many other pipe systems use nominal sizes—the size is a name, not the exact measured dimension. This convention is used across most pool and spa systems and other plumbing areas so that pipes and fittings remain compatible.
Why pipe sizes don’t match the measurements
The Nominal Pipe Size (NPS) system standardises pipe dimensions so that pipes, fittings, valves, and accessories interoperate.
Plumbers work with these nominal names every day, but DIYers can be tripped up if they try to match by a tape-measure alone.
How to Measure Pipe Correctly
-
Pipe size is identified by:
- The pipe’s Outside Diameter (OD).
- The fitting’s Inside Diameter (ID) (socket opening).
- Pipe Class / Schedule (e.g., Class 9, 12, 18 or Sch 40) relates to wall thickness and therefore the Internal Diameter (ID) and pressure rating.
- The outside diameter of a fitting is not useful (wall thickness varies by manufacturer).
Hose & Tube Dimensions
Common flexible hose sizes used in pool/spa systems (approximate IDs).
| Imperial Name | Metric Name | Inside Diameter (ID) |
|---|---|---|
| 3/8" | 9–10 mm | ~9 mm |
| 3/4" | 19 mm | ~19 mm |
BSP – British Standard Pipe Thread Sizes
BSP thread names are also nominal. The thread OD will not equal the nominal name.
| BSP Thread Size Naming | Outside Diameter (mm / inch) | TPI |
|---|---|---|
| 1/16" BSP | 7.7 mm / 0.304" | 28 |
| 1/8" BSP | 9.7 mm / 0.383" | 28 |
| 1/4" BSP | 13.16 mm / 0.518" | 19 |
| 3/8" BSP | 16.66 mm / 0.656" | 19 |
| 1/2" BSP / 15 mm | 20.99 mm / 0.825" | 14 |
| 5/8" BSP | 22.99 mm / 0.902" | 14 |
| 3/4" BSP / 20 mm | 26.44 mm / 1.041" | 14 |
| 7/8" BSP | 30.20 mm / 1.189" | 14 |
| 1" BSP / 25 mm | 33.25 mm / 1.309" | 11 |
| 1-1/4" BSP | 41.91 mm / 1.650" | 11 |
| 1-1/2" BSP / 40 mm | 47.80 mm / 1.882" | 11 |
| 2" BSP / 50 mm | 59.61 mm / 2.347" | 11 |
| 2-1/4" BSP | 65.71 mm / 2.587" | 11 |
| 2-1/2" BSP | 75.18 mm / 2.960" | 11 |
| 3" BSP | 87.88 mm / 3.460" | 11 |
| 4" BSP | 113.03 mm / 4.450" | 11 |
| 5" BSP | 138.43 mm / 5.450" | 11 |
| 6" BSP | 163.83 mm / 6.450" | 11 |
