Zodiac Rear Float / Back Cover Assembly Bypass - EvoLux EX4000/EX5000/EX5050/EX6000/EX6050 iQ, Viron QT1000/QT1050 - R0863200
Genuine Zodiac / Astralpool R0863200 - the rear float and back cover assembly for the VR platform robotic pool cleaner. It closes off the rear of the cover and provides buoyancy at the back of the machine.
- We keep these physically in stock for fast shipping or local pick-up, unlike most drop-shipping websites.
- Shipped from VIC, NSW, WA, QLD
Suits the following robotic pool cleaners
- Zodiac EvoLux EX4000 iQ, EX5000 iQ, EX5050 iQ, EX6000 iQ, EX6050 iQ
- Astralpool Viron QT1000, QT1050
Part details
- Manufacturer part number: R0863200
- Assembly: Rear float / back cover with bypass
- Also supplied within: Complete cover assemblies R0865900 and R0867200
- Platform: VR (EvoLux / Viron QT)
- Genuine: Yes, genuine Zodiac / Astralpool spare part
When to replace it
- Float has taken on water and the cleaner sits heavy at the rear
- Assembly is cracked, split or has broken mounting points
- Cleaner floats nose-down or will not hold its attitude while climbing
- Back cover no longer seats or clips into the main cover
If the cover panel itself is also damaged, the complete cover assembly may work out better value than replacing parts individually.
Fitment disclaimer
The models listed above are the applications we have been able to confirm. Zodiac and Astralpool share components across the EvoLux and Viron QT ranges and revise part numbers over time, so this list may not be exhaustive and your machine may use a different part. Always match the part number on your existing component, or contact us with photos plus your model and serial details, before ordering.
As with all products, these must be diagnosed and fitted by a qualified and experienced person.
