Astralpool / Zodiac Motor Foot Bolt M10 x 25 Hex Washer Head 40173
Genuine Fluidra M10 x 25mm hex washer head bolt, part number 40173. This is the current motor hold-down bolt, and it is the listed replacement for the superseded 40156. Sold individually.
- Physically Stocked, unlike most "drop-shipping" websites.
- Shipped from VIC, NSW, WA, QLD
Supersedes 40156
If your parts diagram or older paperwork calls for 40156, this is the part to order. Astralpool discontinued 40156 and directs to 40173 in its place.
What It Does
These bolts hold the motor down onto the motor foot, clamping through the rubber anti-vibration inserts. The integral washer head spreads the load so the bolt does not pull through the mount.
When To Replace
- The head has corroded and no longer takes a socket cleanly
- The bolt is seized, or snapped during removal
- Fitting a new motor, foot or rubber inserts and refreshing the fasteners as a set
Fitting Notes
Snug only. These clamp through rubber inserts, and winding them down hard crushes the rubber solid, which removes the vibration isolation the mounts exist to provide — the result is a pump that suddenly sounds much louder on the pad. Tighten until the motor is stable and stop there.
Related Parts
- 4005002 — motor foot, graphite pearl (buy here)
- 40056 — V2 rubber insert (buy here)
- 40272 — M8 brass hex nut (buy here)
- 78772 — M8 x 50mm seal plate bolt (buy here)
Fits These Pumps
- Astralpool CTX — CTX 180, 280, 360, 400, 500 (including MkII)
- Astralpool E-Series — E 140, E 170, E 230
- Astralpool Viron XT — P320 XT, P520 XT
- Astralpool XP range
Common search terms: Astralpool 40173, 40156 replacement bolt, M10 x 25 motor bolt, CTX motor hold down bolt, pump motor foot bolt.
