Coming Soon - BWT Pearl HPF Inverter Pool Heat Pump - Front Discharge - 10kW to 27kW

BWT Pearl HPF Inverter Pool Heat Pump - Front Discharge

Full DC inverter pool heating with Wi-Fi app control, R32 refrigerant, automatic output regulation and a 25 year titanium heat exchanger warranty.

• Physically Stocked, unlike most 'drop-shipping' websites.
• Shipped from VIC, NSW, QLD, WA

The BWT Pearl HPF is the front discharge model in the Pearl inverter range. A full DC inverter compressor paired with a brushless variable speed fan lets the unit ramp its output up or down to match demand, rather than simply cycling on and off. The result is a higher seasonal COP, lower running costs and noticeably quieter operation than a fixed speed heat pump.

Front discharge suits the majority of Australian equipment pads, where the unit can exhaust into open space in front of it. Heating, cooling and automatic modes are all standard, and BWT Connect Wi-Fi is built in so the unit can be run and monitored from a smartphone.

Key Features

• Full DC inverter - variable output compressor and brushless fan for efficient, quiet running
• R32 refrigerant - lower global warming potential than R410A
• Intelligent operating mode - autoregulates output by cross-referencing water and air temperature
• Three operating modes - Boost, Smart and ECO
• Heating, cooling and automatic operation from a colour digital touch screen
• BWT Connect inside - Wi-Fi module fitted as standard, accessible through a side panel
• TechniCenter supervision - remote diagnostics, settings access and firmware updates over Modbus
• Low noise levels - noise reduction insulation on all panels, compressor and fan speed adjust automatically
• Exclusive low temperature system - reverse-cycle defrosting, compressor housing preheating, evaporator antifreeze and automatic piloting
• Titanium heat exchanger - suited to salt, mineral and chlorinated water

Models and Heating Capacity

A 24.2 kW model (Pearl HPF 24) also exists within the BWT range. Contact us if you need that capacity and we will source it.

BWT Smart Control

Pearl inverter heat pumps use a double-entry regulation system that anticipates the pool energy requirement instead of reacting to it. Power delivery is optimised by comparing air temperature against water temperature, so the unit only draws what the pool actually needs.

• Boost Mode - fastest heat-up, maximum output
• Smart Mode - balanced output and running cost
• ECO Mode - lowest energy consumption and lowest noise

A higher COP means a lower electricity bill, and lower noise levels mean better comfort for you and your neighbours.

BWT Connect and the TechniCenter

A Wi-Fi device is fitted as standard inside every Pearl inverter heat pump and is reached through a side panel. Pairing is done by scanning the QR code on the machine, entering the network security code and pressing the pairing button - there is no separate module to buy or wire in.

Once connected, the heat pump reports to the BWT TechniCenter. Where an error code is raised, BWT technicians can see the fault, access settings through a secure interface and adjust, optimise or update the unit remotely over Modbus. In practice that means a good proportion of faults are diagnosed, and often resolved, without a service call - and frequently before the pool owner has noticed anything is wrong.

Power Supply

• Single phase across the full 10kW to 27kW range
• Electrical connection must be carried out by a licensed electrician

Warranty

• 25 years - titanium heat exchanger
• 10 years - compressor
• 5 years - parts

Sizing Guidance

Heat pump sizing depends on pool volume, surface area, whether a blanket is used, your climate zone and how early in the season you want to start swimming. As a rough guide, an unblanketed pool loses most of its heat from the water surface overnight, so a pool cover will do more for your running costs than any other single change. Undersizing is the most common mistake - a unit that runs continuously and never reaches setpoint costs more to run than a correctly sized one.

If you are unsure which capacity suits your pool, send us your pool dimensions, location and whether it is covered, and we will size it for you.

Note: This product must be installed and serviced by a qualified pool equipment technician or licensed professional. We carry more spare parts than anyone.

Manufacturer Brochures, Manuals & Part Numbers

Need specifications, dimensions, wiring diagrams or more product information? See the manufacturer documents:Front Discharge Heat Pump Brochure | Pearl HPF Installation & User Handbook
