Astralpool Display Screen for ECO Inverter 7, 8, 12kW Heat Pumps 72200077
Astralpool Display Screen for ECO Inverter 7, 8, 12kW Heat Pumps 72200077 is temporarily out of stock and will ship as soon as it's available.
Don't Guess - Ask Us!
Don't Guess - Ask Us!
Not sure if it’s the right part? Send us a message and a photo of what you’re replacing, or what you need, and we’ll help make sure you get the right part the first time.
Delivery and Shipping Info*
Delivery and Shipping Info*
Free Shipping over $99 for most products. Choose Express Post for fastest shipping!
Astralpool Display Screen for ECO Inverter 7, 8, 12kW Heat Pumps 72...
Astralpool Display Screen for ECO Inverter 7, 8, 12kW Heat Pumps 72200077 is temporarily out of stock and will ship as soon as it's available.
Genuine Astralpool heat pump display — the front control panel / wired controller used to set water temperature, select heating, cooling or auto mode, run the timers, and read operating status and fault codes.
Part Number: 72200077
- Brand: Astralpool (Fluidra)
- Part type: Heat pump display / control panel — genuine replacement
Used On
ECO Inverter range:
- 78566 — ECO Inverter 7kW (also listed by Astralpool as ECO iHP70)
- 78567 — ECO Inverter 8kW (also listed as ECO iHP90)
- 78568 — ECO Inverter 12kW (also listed as ECO iHP120)
- 78568-II — ECO Inverter 12kW
Check The Number On The Back Of Your Existing Display
Astralpool lists two different displays against the ECO Inverter 8kW (78567) and 12kW (78568), so the heat pump model number alone is not enough to identify the right part. Remove your existing display and read the part number printed on the back of it:
- 72200077 — this listing. Suits the ECO Inverter 7kW (78566), 8kW (78567), 12kW (78568) and 78568-II.
- 72200452 — Astralpool Display Screen 72200452. Suits the ECOLite Inverter 12kW, 16kW and 18kW, and the ECO Inverter 8kW, 12kW and 18kW (78596).
If the number on the back does not match either part, send us a photo of the label and we will identify it.
Common Reasons For Replacement
- Blank, dead or partially lit screen
- Missing or faded display segments
- Unresponsive or intermittent keys
- Communication fault between the display and the main control board
- Water ingress or corrosion behind the panel
The display and the main control board are separate parts. Confirm which has failed before ordering — a fault shown on the screen is not always a fault in the screen.
