Zodiac Rear Grid CN B (Black) - FreeRider FR1000/FR2000 iQ - R0903400
Zodiac Rear Grid CN B (Black) - FreeRider FR1000/FR2000 iQ - R0903400 is temporarily out of stock and will ship as soon as it's available.
Zodiac Rear Grid CN B (Black) - FreeRider FR1000/FR2000 iQ - R0903400
Genuine Zodiac R0903400 - the black rear grid for the CN chassis robotic pool cleaner. The grid covers the rear discharge opening, screening out large debris while allowing filtered water to exit. This is the B variant grid.
- We keep these physically in stock for fast shipping or local pick-up, unlike most drop-shipping websites.
- Shipped from VIC, NSW, WA, QLD
Important - A or B variant
Two rear grids are used across the CN chassis and they are not interchangeable, despite both being black:
- Rear grid CN B, black - R0903400: this product, Zodiac branded
- Rear grid CN A, black - R0902100: the A variant used on other CN chassis cleaners
Match the variant letter on your existing part before ordering. The matching B variant parts are the navy blue body housing R0902600 and the smoke complete cover R0902700.
Suits the following robotic pool cleaners
- Zodiac FreeRider FR1000 iQ (WR000527)
- Zodiac FreeRider FR2000 iQ (WR000508)
Part details
- Manufacturer part number: R0903400
- Component: Rear grid
- Variant: B
- Colour: Black
- Branding: Zodiac
- Chassis platform: CN
- Genuine: Yes, genuine Zodiac spare part
When to replace it
- Grid is cracked, broken or has lost sections of its mesh
- Grid has come off and been lost in the pool
- Retaining clips no longer hold it to the housing
- Cosmetic restoration of an otherwise sound cleaner
Fitment disclaimer
The models listed above are the applications we have been able to confirm. Zodiac and Astralpool share the CN chassis across several cleaner families with different trim variants and branding, and part numbers are revised over time, so this list may not be exhaustive and your machine may use a different part. Always match the part number on your existing component, or contact us with photos plus your model and serial details, before ordering.
As with all products, these must be diagnosed and fitted by a qualified and experienced person.
