Spanet SV 1 (SV One) - Spa Controller - Balboa Compatible

SpaNET SV 1 Spa Controller - Balboa Compatible Drop-In Replacement

The SpaNET SV 1, also referred to as the SpaNET SV1 or SV One, is a compact spa control system designed as a Balboa-compatible drop-in replacement for many common Balboa spa controllers using the standard 15-inch heater format.

The SV 1 uses heater dimensions compatible with many Balboa control systems and supports industry-standard AMP and overmoulded AMP equipment plugs, making it particularly suitable for replacement and retrofit applications where an older spa controller is obsolete, unreliable or no longer economical to repair.

It is an ideal replacement option for systems such as the Balboa GS501, along with other compatible Balboa controllers using a similar equipment configuration and 15-inch heater layout.

Key Features

• SpaNET SV Series spa controller
• Balboa-compatible replacement format
• Standard 15-inch heater dimensions
• Compatible with common Balboa-style spa plumbing layouts
• Uses industry-standard AMP or overmoulded AMP plugs
• Suitable for replacement of many older Balboa control systems
• Supports either conventional pump operation or dedicated circulation-pump systems
• Supplied as a complete control system with heater and touchpad

Equipment Configurations

The SpaNET SV 1 can be configured to control:

Configuration 1

• 1 x 2-speed jet pump
• 1 x blower
• 1 x spa light

Configuration 2

• 1 x circulation pump
• 1 x single-speed jet pump
• 1 x blower
• 1 x spa light

This makes the SV 1 suitable for many common portable spa configurations without requiring a larger multi-pump control system.

Balboa Replacement Applications

The SpaNET SV1 is particularly useful when replacing older Balboa control boxes where retaining the existing plumbing and standard equipment connections is desirable.

Potential replacement applications include:

• Balboa GS501
• Balboa systems using a 15-inch heater
• Balboa systems using standard AMP equipment connections
• Older spa control systems with one jet pump, blower and light
• Circulation-pump spas with one separate jet pump

Compatibility must always be confirmed against the existing controller, heater plumbing, pump arrangement, electrical supply and equipment connections before ordering.

What's Included

• SpaNET SV 1 control box
• Integrated heater assembly
• SpaNET touchpad

A Modern Replacement for Older Spa Controllers

Many older Balboa spa controllers remain fitted to Australian spas long after the original control system has become obsolete or difficult to source.

The SpaNET SV 1 provides a practical modern replacement platform while retaining compatibility with common spa-industry equipment connections and the widely used 15-inch heater format.

Rather than replacing pumps, blowers and other serviceable equipment simply because the original controller is obsolete, the SV 1 can allow the existing spa equipment to be retained where compatible.

Compatibility

The SpaNET SV 1 should not be confused with the SpaNET SV Mini 1 / SVM1. The SV 1 / SV1 / SV One is a separate SpaNET control system.

Before ordering, compare:

• Existing controller model
• Heater length and plumbing position
• Pump configuration
• Circulation pump requirements
• Blower connection
• Light connection
• Equipment plug type
• Electrical supply and current requirements
• Available mounting space

If replacing an existing Balboa controller such as a GS501, confirm the existing equipment configuration before ordering to ensure the correct replacement setup.

Additional Specifications

Further technical specifications will be added as they become available, including:

• Supply current and electrical ratings
• Heater wattage
• Control box dimensions
• Heater dimensions
• Touchpad dimensions
• Temperature sensor configuration
• Supported light types
• Detailed pump current limits
• Wiring and installation information
• Additional compatible Balboa controller models
