Spanet SV2 Control Box w/ Heater - no Touchpad. For replacing faulty SV2 & VSX2 control systems.

he new SV2-VH spa control featuring a 3kW Smart Variable Heater. Make optimum use of lower current power supplies. All SV Series controllers come with the following featurers: Multi Phase Capable, Heat Pump interface, Power Save Technology.

SPECIFICATIONS

Power:

• 1 phase 230-240v AC
• 3 phase 400-415v AC

• 50/60Hz

• MAX total current 20amp or 16amp per phase


Controller:

• 544x309x90mm 5kg

Outputs:

• Heater: 3kw Variable
• Light x 1 (needs to be a Spanet LED light)

• Touch Pad socket: x 1

• Circulation Pump: x1 (Adj 1-24 hour)

• Ozone : x 1

• Air Blower: x1 (Vari Spd)

• Pump: 1 x 1 or 2speed pump
