Onga / Balboa Spa Bath Pump Touchpads - Obsolete
Onga / Balboa spa bath pumps, touchpads, and parts have been discontinued and are no longer available. See below for replacement options. The pump and control method will need to be replaced together.
These pumps were commonly used in spa baths from Stylus, Monarch, Lanark and many others, including systems sold under the Onga Bathmaster, Bathtronic and DR names.
Find your existing pump model number below and choose the recommended replacement option. The correct replacement depends on your existing pump size, plumbing, touchpad cable access, and whether your spa bath also has an air blower.
Replacement Notes
There are two main replacement methods. The best option depends on whether you want to keep the existing plumbing arrangement, and whether a new control cable can be run from the bath edge to the new pump.
-
* Option 1 - Air Button Replacement:
Usually keeps the same plumbing layout. The old electronic touchpad is removed and the existing touchpad hole normally needs to be drilled or enlarged to suit a new air button. An air tube must then be run between the air button and the new pump. -
** Option 2 - SensaTouch Replacement:
Requires minor replumbing. A new touchpad cable must be pulled through from the pump to the bath edge. The new touchpad will generally fit the original touchpad hole, but this should be checked before installation.
Bathtronic / Bathmaster / Stylus Models
-
Balboa / Onga 2372, 2373, 2382, 2383, 2393
- * Option 1: Balboa 2381 + Air Button
- ** Option 2: SensaTouch 1.0hp
-
Balboa / Onga 2377, 2387, 2392, 23920100, 2393, 2397, 2401, 2402, 2403, 2404, 2407
- * Option 1: Balboa 2391 + Air Button
- ** Option 2: SensaTouch 1.5hp
Onga DR Models
-
DR pumps without heater: 2376, 2386, 2396, 2409
- Option 1: Balboa 2388 + Air Button
Other Onga / Balboa Part Numbers and Model Numbers
These Onga / Balboa spa bath pumps may be identified by the short model number or by the full 8-digit part number printed on the pump label. For example, 2381 may also appear as 23810100 or B-23810100, and 2391 may appear as 23910100 or B-23910100.
Common related Onga / Balboa 200 Series spa bath pump numbers include:
- Air switch pumps without heater: 2378 / 23780100, 2388 / 23880100, 2398 / 23980100, 2408 / 24080100
- Hot pump air switch models: 2371 / 23710100, 2381 / 23810100, 2391 / 23910100, 23911100, 2401 / 24011100
- Bathmaster electronic touchpad models: 2372 / 23720100, 2382 / 23820100, 2392 / 23920100, 23921100, 2402 / 24021100
- Bathtronic electronic touchpad models: 2373 / 23730100, 2383 / 23830100, 2393 / 23930100, 23931100, 2403 / 24031100
- DR touch-button models: 2377, 2387, 2397, 2407
- DR non-heated models: 2376, 2386, 2396, 2409
Some labels may include prefixes such as B-, for example B-23810100, B-23910100 or B-23880100. The original electronic touchpads are obsolete, so replacement usually requires changing the pump and control method, not just the touchpad.
