Balboa BP8 Retrofit Spa Pack (Complete with Inline Heater) - The most "universal" spa control system on the market. Replaces all BP series controllers such as BP601G1, BP6013G1, BP6013G2, BP6013G3, Dominator, and SIBP601X. Additionally, it can be used to replace the GS and GL series (with a new touchpad), as well as other models like Revolution, Colossus, and Viper.

This versatile retrofit pack is designed to replace a wide range of Spa control systems. It offers 18 different setup configurations.

Supports the following configurations:

• Circulation pump + 3 x single-speed jet pumps
• Circulation pump + 1 x two-speed pump + 2 x single-speed jet pumps
• One two-speed pump + 2 x single-speed jet pumps
• One blower (or possibly a fourth pump)
• Ozone
• Spa light
• 3 kW inline heater

WiFi & Smart Device Compatibility:

• Works with BWA WiFi module (sold separately) for smartphone control
• Compatible with CMS WiFi and SpaTouch 4 modules (sold separately)

Topside Panel Compatibility:
Compatible with Balboa TP-series touchpads (some touchpad options may depend on output configuration), including:

• TP200
• TP400
• TP500
• TP600
• TP700 / TP740
• TP800 (colour touchscreen)
• All SpaTouch touchscreen panels:
  • Spatouch Mini, Spatouch 3 - 5", Spatouch 3 - 7", Spatouch 4

Installation Notes:

• Touchpad hole will need to be modified for most touchpad types
• 32A max load (single phase), 16A max (three phase)
• If using 3 jet pumps, it may be necessary to limit to 2 pumps running simultaneously depending on amperage draw

Important:

• Ensure compatibility with your existing system before purchase
• Not compatible with Microsilk systems
• Programming must be completed before connecting any two-speed pump
