Astralpool Impeller CTX180 FX 190 P310 40060R

Astralpool Impeller CTX 180 / FX 190 / P310 / CX180 40060R

This is the genuine Astralpool impeller, part number 40060R, the smallest impeller in the CTX range. It covers the CTX 180, FX 190, P310 and CX180 pumps. CTX impellers are sized to the model number and are not interchangeable across the range — the pump body looks identical from CTX 180 through CTX 610, but each takes its own impeller.

• Physically Stocked, unlike most "drop-shipping" websites.
• Shipped from VIC, NSW, WA, QLD

The CTX Impeller Rule (rev. CTX-1.0)

1. Read the model number on the pump badge — the three digits after CTX or CX are what matter. 180, 280, 360, 400, 500 and 610 each take a different impeller.
2. Match the model to the table below. The 40060R is the CTX 180 / FX 190 / P310 / CX180 impeller.
3. If the badge says Viron rather than CTX or CX, stop. Viron XT pumps take 40060X (P320) or 40060Z (P520).
4. If you cannot read the badge, send us a photo of the pump and the old impeller. We would rather identify it for you than have it come back.

Which CTX Impeller Do I Need?

Related CTX Parts

• 40071A — diffuser, CTX 180 / 280 / 360 / 400 (buy here)
• 75508 / PS3868 — mechanical seal, BX / TX / CX / E / CTX (buy here)
• 70022 — seal plate o-ring, new style Aug 2014 onwards
• 70004 — square seal plate o-ring, old style (buy here)
• 40098 / 40030 — seal plate, Aug 2014 onwards and the July 2018 revision
• 40097 / 40031 — wet end, pre- and post-July 2018
• 40065 — basket (buy here)
• 40089 — lid complete with o-ring (buy here)
• 70006 — lid o-ring (buy here)

Symptoms of a Failed or Worn Impeller

• Motor runs at normal speed and normal noise, but flow and filter pressure are both down
• Pump takes far longer to prime, or will not hold prime, with no air leak found on the suction side
• Grinding, rattling or a rhythmic knock from the wet end
• Pump humming but not turning — usually debris jammed in the impeller, often after the hair and lint basket has split
• Visible debris packed into the vane passages, or vane tips worn back and rounded
• Cracked or spun hub after the pump has run dry

When to Replace

Replace the impeller when the vanes are worn, chipped or cracked, when the hub has spun, or when the pump has run dry and the plastic has distorted. Blocked vanes can often be cleared rather than replaced — check that first. Because the mechanical seal is disturbed whenever the impeller comes off, we recommend fitting a new mechanical seal at the same time rather than reusing a seal whose faces have been separated.

Frequently Asked Questions

Will this fit a CTX 280?
No. Each CTX model takes its own impeller. The CTX 280 uses 40060S.

Does it fit a CX180 or P310?
Yes. Astralpool lists 40060R as covering the CTX 180, FX 190, P310 and CX180.

Can I fit a larger impeller to get more flow?
No. The impeller is sized to the motor. A larger impeller on a smaller motor draws excessive current and will shorten the motor's life.

Do I need a new mechanical seal when I replace the impeller?
We recommend it. The seal is split apart as soon as the impeller comes off, and reused seal faces are the most common cause of a leak after an impeller change. These pumps use the BX / TX / CX / E / CTX seal.

Is this a genuine Astralpool part?
Yes. We are an authorised Astralpool and Fluidra dealer and warranty agent.

Manufacturer Catalogues, Diagrams & Part Numbers

Need exploded views, spare part numbers, product numbers or diagrams? See the manufacturer catalogue: Astralpool Catalogue 2026

Before ordering: confirm this part is correct for your pump. Use the catalogue above, seek professional assistance, or contact us with photos of your existing part, model details, serial numbers and any labels. As with all products, this must be diagnosed and fitted by a qualified and experienced person. This is a special-order item.

Common search terms: Astralpool 40060R, CTX180 impeller, FX190 impeller, P310 impeller, CX180 impeller, Astral Hurlcon CTX 180 impeller.
