Aquaflo 1/15th HP Circ-Master HP CMCP CMHP - Spa Circulation Pump - GENUINE - Emerson - Best Prices

  • From $385.00
  • Save $290


GENUINE Aquaflo Circ-Master 1/15 HP Emerson spa circulation pump CMCP/FMHP/CMHP. IN STOCK. FAST SHIPPING.  This is the latest version CMHP that supercedes all previous models. The best, most economical high flow circulation pump in the industry at approx 170w.

New style pump comes with capacitor box on side, and now has a cooling fan & cowl. 48-frame motor for powerful, economical running. When cared for, these pumps often last 10 years or more.

This is the Australian-Approved version. Some other websites and eBay sellers are selling a non-compliant version with no electrical approvals. This is a Genuine Aqua-Flo Circmaster pump.

Used on SCS Industries spas such as Signature Spas, Bullfrog, Leisurite, Lanark, Cyclone Spas, Designer Series Spas, Sundance, Leisurite and many others.

Specifications:
HP: 1/15
RPM: 1425
AC VOLTS: 220-240 V
CURRENT: 0.66 A
S.F.: 1.25
S.F.A.: 0.03 A
1/15th HP, 220-240v, 50Hz, 0.62A, 1425 rpm.

Details:

  • Pump input and output in 1.5’’ (40mm)
  • 1.5’’ (40 mm) suction and backflow diameter for an increased circulation performance
  • ~6UF capacitor
  • Thermal overheat detector to preserve and increase the motor’s lifespan
  • Ultra silent functioning
  • Material adapted for spas and pools
  • The Circ-Master HP circulation pump is designed to function without risk of overheating and can run 24 hours a day.

May also have these part numbers and/or names:

CircMaster,
CMHP, CMCP, CMXP, FMCP, FMHP
CMHP-550114
Model: 02410004-2 Code 08155
Model: 02410004-2 Code: 05189
Model: 02410004-2 code 07345
Model: 02410004-251
Model: 02410004-2
Model: A-02410004-2510

Model: K55MYRPY-2111
Model: K55MYKHF-9557
Model: K55MYGRD-8367

Part No: 9352-9306
Part No: 9352-9309
SD6500-911
3J10070-0E,

Spa Industries: APUMC1562A,
Spa Industries: APUMC1552A,
Waterway Plastics Iron Might
Circmaster Emerson circulation pump 1/15HP
Emerson 1563 Spa Motor
Aquaflo XP2 06040000-2
Gecko Ref : 06334000-2040
Sundance / Jacuzzi Ref : 6500-911
Waterway Iron Might

May also Supercede the following:

00707000-2510, 00707001-2510, 00707002-2510, 00710392-2500, 00710392-2510, 02093377-2110, 02093008-2100, 02093377-2110, 02093008-2110, 02093377-2110, 02093008-2130, 02093377-2110, 02093008-2520, 02093377-2110, 02093377-2110, 02093377-2110, 02093656-2010, 02093377-2110, 02093656-2110, 02093377-2110, 02093656-2130, 02093377-2110, 02093656-2510, 02093377-2110, 02093700-2110, 02093377-2110, 02093700-2510, 02093377-2110, 02407001-2510, 02093377-2110, 02407002-2510, 02093377-2110, 02407384-2510, 02093377-2110, 02407422-2010, 02093377-2110, 02407422-2510, 02093377-2110, 02410000-2500, 02093377-2110, 02410000-2510, 02093377-2110, 02410003-2500, 02093377-2110, 02410004-2510, 02093377-2110, 02410013-2510, 02093377-2110, 02410014-2510, 02093377-2110, 02410377-2510, 02093377-2110, 02410392-2110, 02093377-2110, 02410402-2510, 02093377-2110, 02410498-2000, 02093377-2110, 02410498-2100, 02093377-2110, 02410662-2110, 02093377-2110, 02410701-2510, 02093377-2110, 02410974-2510, 02093377-2110, 02410979-2510, 02093377-2110, 02415001-2010, 02093377-2110, 02415001-2500, 02093377-2110, 02415001-2510, 02093377-2110, 02415002-2010, 02093377-2110, 02415002-2310, 02093377-2110, 02415003-2510, 02093377-2110, 02415004-2510, 02093377-2110, 02415005-2010, 02093377-2110, 02415005-2510, 02093377-2110, 02415006-2510, 02093377-2110, 02415422-2010, 02093377-2110, 02415422-2510, 02093377-2110, 02420000-2510, 02093377-2110, 02420001-2500, 02093377-2110, 02420002-2510, 02907422-2510, 02910422-2510, 02910498-2000, 06040000-2300

Circmaster Spare Parts:

- Unions
- Impellers
- Mechanical Seal
- Casing / Body O-Ring Seal
